Mission Engineering Aero VM-1 Passive Volume Pedal
Mission Engineering Aero VM-1 Passive Volume Pedal
Condition: Second-hand, in excellent condition with minimal cosmetic wear. No accessories included (case, power supply etc).
Photos shown are of the product on hand.
Sold
Sold for $280
This one’s found its new owner
You just missed out. One-of-a-kind gear lands every week, and some of it goes the same day. Here’s what came in since.
Open 7 days · 16 Chrome St · Call (07) 3392 6888
Key details
- Requires a 9V DC Negative Tip Power Supply or 9V Battery.
Overview
The VM-1 Aero is a passive volume pedal with switchable tuner mode intended for use with electric guitars with passive pickups. With a passive ‘no tone suck’ circuit, this pedal features an isolated tuner output and integrated mode switch. All VM-1 Aero models also include Missions illuminated base. Visible from any position, the transparent acrylic base illuminates indicating selected mode. Power consumption is approximately 20mA.
To enable tuner mode, push down firmly on the front of the rocker to engage the toe switch. If power is connected, the base will illuminate red to indicate tuner mode. The tuner output will now be enabled. With the rocker at toe down, a small amount of signal is routed to the main output for audible tuning. Move the rocker back to the heel down position for silent tuning.
(Missionengineering.com)
Specs
| Pedal Type | Passive Volume Pedal |
|---|---|
| Chassis Material | Aerospace-grade Aluminum |
| Input Impedance | 470K Ohm |
| Circuitry | Completely passive ("no tone suck"); operates without power |
| Modes | Active Mode (Green/Blue base) and Tuner/Mute Mode (Red base) |
| Switching | Integrated mode/mute toe switch |
| Potentiometer | Sealed, maintenance-free, rated for over 1 million cycles |
| Dimensions | 11″ × 4″ × 3″ |
| Weight | 1.6 lbs (approx. 725g) |
| Inputs | 1 × 1/4" TS (Guitar In) |
| Outputs | 2 × 1/4" TS (Main Out, Isolated Tuner Out) |
| Power | 9V DC center-negative power supply or internal 9V battery (Note - Power is required exclusively for the LED base illumination; the volume pedal functions perfectly without power). |
| Battery Life | ~20 hours on a 9V block battery |
